BL-VP101U

BL-VP104U

BL-VP104WU

Browse

-0.32 Megapixel high sensitivity CMOS Sensor
-Full frame (Up to 30 fps) transmission at VGA

(640 x 480) image size
-H.264 and JPEG dual stream output
-High sensitivity with Day & Night (Electrical)
function: 0.9 lx (Color),0.6 lx (B/W) at F2.8
-4x digital zoom controlled by browser
-Smart phone Monitoring

-720p HD images up to 30 fps
-1.0 Megapixel high sensitivity CMOS Sensor
-Full frame (Up to 30 fps) transmission at
1,280 x 720 image size
-H.264 and JPEG dual stream output
-High sensitivity with Day & Night (Electrical)
function: 0.9 lx (Color),0.6 lx (B/W) at F2.8
-1.5x extra zoom under VGA resolution
-Smart phone Monitoring

-720p HD images up to 30 fps
-1.0 Megapixel high sensitivity CMOS Sensor
-Full frame (Up to 30 fps) transmission
at 1,280 x 720 image size
-H.264 and JPEG dual stream output
-High sensitivity with Day & Night (Electrical)
function: 0.9 lx (Color),0.6 lx (B/W) at F2.8
-1.5x extra zoom under VGA resolution
-Smart phone Monitoring
-Wireless Communication (IEEE 802.11n/b/g)
-WPS (Wi-Fi Protected Setup)

BL-VT164U

BL-VT164WU

Browse



	-720p HD images up to 30 fps -1.0 Megapixel high sensitivity CMOS Sensor -Full frame (Up to 30 fps) transmission at 1,280 x 720 image size -H.264 and JPEG dual stream output -High sensitivity with Day & Night (Electrical) function: 0.9 lx (Color),0.6 lx (B/W) at F2.8 -1.5x extra zoom under VGA resolution -Remote Pan and Tilt control -Smart phone Monitoring		-720p HD images up to 30 fps -1.0 Megapixel high sensitivity CMOS Sensor -Full frame (Up to 30 fps) transmission at 1,280 x 720 image size -H.264 and JPEG dual stream output -High sensitivity with Day & Night (Electrical) function: 0.9 lx (Color),0.6 lx (B/W) at F2.8 -1.5x extra zoom under VGA resolution -Remote Pan and Tilt control -Smart phone Monitoring -Wireless Communication (IEEE 802.11n/b/g) -WPS (Wi-Fi Protected Setup) function

WV-SP102E
(Fixed)

WV-SP105E
(Fixed)

Browse

-Progressive scan 320,000 Pixel MOS Sensor
-Full frame (Up to 30 fps) transmission at VGA
(640 x 480) image size
-High sensitivity : 2.0 lx (Color), 1.3 lx (B/W) at
-F2.0 / 0.3 lx (Color), 0.16 lx (B/W) at F2.0
(Wide) with Sens Up 8x
-Dual H.264 and JPEG simultaneous
stream output
-Supports Power over Ethernet (PoE) IEEE
802.3af

-720p HD images up to 30 fps
-Progressive scan 1.3 Megapixel MOS Sensor
-Full frame (Up to 30 fps) transmission at
1,280 x 960 image size
-2x extra zoom under VGA resolution
-High sensitivity : 0.8 lx (Color), 0.4 lx (B/W)
at F2.2 / 0.05 lx (Color),
0.03 lx (B/W) at F2.2 (Wide) with Sens Up 16x
-Dual H.264 and JPEG simultaneous
stream output
-Supports Power over Ethernet (PoE)
IEEE 802.3af

WV-SF132E
(Fixed Dome)

WV-SF135E
(Fixed Dome)

WV-SW152E
(Fixed Dome)

Browse

-Progressive scan 320,000 Pixel MOS Sensor
-Full frame (Up to 30 fps) transmission
at VGA(640 x 480) image size
-VIQS (Variable Image Quality
on Specified area) technology
-High sensitivity: 2.0 lx (Color),
1.3 lx(B/W) at F2.9
-H.264(High profile) dual stream
and JPEG output
-Power over Ethernet (PoE) IEEE 802.3af
-Low profile design for discrete installation

-1.3 Megapixel high sensitivity MOS Sensor
-VIQS (Variable Image Quality on Specified area)
-High sensitivity: 0.8 lx (Color),
0.6 lx(B/W) at F2.2
-H.264 (High profile) dual stream and JPEG output
-Wide coverage Horizontal: 104°, Vertical: 85°
-Power over Ethernet (PoE) IEEE 802.3af
-Low profile design for discrete installation

-Progressive scan 1.3 Megapixel MOS Sensor
-Wide Dynamic Range
-Face Wide Dynamic Range
-VIQS (Variable Image Quality on Specified area) -High sensitivity: 0.6 lx (Color),
0.4 lx(B/W) at F2.2
-H.264 (High profile) dual stream and JPEG output
-Power over Ethernet (PoE) IEEE 802.3af
-IP66 rated water and dust resistant
-Vandal resistant mechanism for high reliability
-Wide coverage (Horizontal: 104 °, Vertical: 85 °)

WV-SW155E
(Fixed Dome)

Browse



	-Progressive scan 1.3 Megapixel MOS Sensor -Wide Dynamic Range and ABS (Adaptive Black Stretch) -Face Wide Dynamic Range -VIQS technology -High sensitivity: 0.8 lx (Color), 0.6 lx(B/W) at F2.2 -H.264(High profile) dual stream and JPEG output -Power over Ethernet (PoE) IEEE 802.3af -IP66 rated water and dust resistant -Vandal resistant mechanism for high reliability

WV-ST162E
(Pan/Tilt)

WV-SF165E
(Pan/Tilt)

WV-SW172E
(Pan/Tilt)

Browse



1.3 Megapixel high sensitivity MOS Sensor Full frame (Up to 30 fps) transmission at SVGA (800 x 600) image size Panning/tilting and Preset Map Shot function realizes wide range monitoring. Face Wide Dynamic Range High sensitivity with Day & Night (electrical) function: 0.6 lx (Color), 0.5 lx(B/W) at F2.2 H.264 (High profile) dual stream and JPEG output Power over Ethernet (PoE) IEEE 802.3af	720p HD images up to 30 fps 1.3 Megapixel high sensitivity MOS Sensor Full frame (Up to 30 fps) transmission at 1,280 x 960 image size Panning/tilting and Preset Map Shot function realizes wide range monitoring. Face Wide Dynamic Range High sensitivity with Day & Night (electrical) function: 0.6 lx (Color), 0.5 lx(B/W) at F2.2 H.264 (High profile) dual stream and JPEG output Power over Ethernet (PoE) IEEE 802.3af	1.3 Megapixel high sensitivity MOS Sensor Full frame (Up to 30 fps) transmission at SVGA (800 x 600) image size Panning/tilting and Preset Map Shot function realizes wide range monitoring. Face Wide Dynamic Range High sensitivity with Day & Night (electrical) function: 0.6 lx (Color), 0.5 lx(B/W) at F2.2 H.264 (High profile) dual stream and JPEG output Power over Ethernet (PoE) IEEE 802.3af IP55 rated

WV-SW175E
(Pan/Tilt)

WV-SW174W
(Pan/Tilt)

Browse

720p HD images up to 30 fps
1.3 Megapixel high sensitivity MOS Sensor
Full frame (Up to 30 fps) transmission at 1,280 x 960 image size
Panning/tilting and Preset Map Shot function realizes wide range monitoring.
Face Wide Dynamic Range
High sensitivity with Day & Night (electrical) function: 0.6 lx (Color), 0.5 lx(B/W) at F2.2
H.264 (High profile) dual stream and JPEG output
Power over Ethernet (PoE) IEEE 802.3af
IP55 rated

WV-SC384
(DOM)

WV-SC385
(DOM)

Browse

720p HD images up to 30 fps
Newly developed 1.3 Megapixel MOS Sensor
Full frame (Up to 30 fps) transmission at 1,280 x 960 image size
36x extra optical zoom at VGA resolution with 8x digital zoom enabling 288x zoom.
Wide Dynamic Range and ABS (Adaptive Black Stretch) technologies deliver wider dynamic range compared with conventional cameras.
Face Super Dynamic technology ensures clear face image.
High sensitivity: 0.6 lx (Color), 0.5 lx (B/W) at F1.6 (Wide)
Supports Power over Ethernet (PoE) IEEE 802.3af
ONVIF compliant model

720p HD images up to 30 fps
Newly developed 1.3 Megapixel double speed MOS Sensor
Full frame (Up to 30 fps) transmission at 1,280 x 960 image size
36x extra optical zoom under VGA resolution with 12x digital zoom enabling 432x zoom.
Super Dynamic 128x wider dynamic range
Face Super Dynamic technology ensures clear face image.
High sensitivity: 0.5 lx (Color), 0.06 lx (B/W) at F1.6 (Wide) / 0.031 lx (Color), 0.004 lx (B/W) at F1.6 (Wide) with Sens Up 16x
Supports Power over Ethernet (PoE) IEEE 802.3af
Desktop/Ceiling position choice and various optional brackets for versatile installations
ONVIF compliant model
